Pattern — Observability with OpenTelemetry¶

TL;DR: OpenTelemetry SDK in every service, Application Insights as the backend, W3C Trace Context propagated end-to-end, structured logs with correlation IDs everywhere, dashboards in Azure Workbooks, SLI/SLO + error budgets to drive engineering effort. Don't roll your own.

Problem¶

A modern data platform spans a dozen services per request — portal → BFF → AI service → vector search → AOAI → response. Without distributed tracing, debugging a "this one request was slow" report means hunting through 6 separate log streams hoping timestamps line up. With OpenTelemetry, every log line and every span carries the same trace ID, and one click in App Insights shows you the full request waterfall.

Architecture¶

flowchart LR
    subgraph User
        Browser[Browser]
    end

    subgraph Portal[Portal — React + FastAPI BFF]
        React[React app<br/>OTel JS SDK]
        BFF[FastAPI BFF<br/>OTel Python SDK<br/>+ auto-instrumentation]
    end

    subgraph AI[AI Services]
        RAG[RAG service<br/>OTel SDK]
        AOAI[Azure OpenAI<br/>logs trace context<br/>via App Insights connector]
        Search[AI Search<br/>diagnostic logs]
    end

    subgraph Backend[Data Backend]
        DAB[Data API Builder]
        Synapse[Synapse SQL]
    end

    subgraph Telemetry[Application Insights / Log Analytics]
        AI1[Distributed traces]
        AI2[Structured logs]
        AI3[Metrics]
        AI4[Workbooks + alerts]
    end

    Browser -- traceparent --> React
    React -- traceparent --> BFF
    BFF -- traceparent --> RAG
    BFF -- traceparent --> DAB
    RAG -- request --> AOAI
    RAG -- request --> Search
    DAB -- query --> Synapse

    React -. spans .-> AI1
    BFF -. spans + logs .-> AI1
    RAG -. spans + logs .-> AI1
    AOAI -. AI logs .-> AI2
    Search -. diagnostic .-> AI2
    DAB -. spans .-> AI1
    Synapse -. diagnostic .-> AI2

    AI1 --> AI4
    AI2 --> AI4
    AI3 --> AI4

Pattern: end-to-end trace propagation¶

Every service:

1. Reads incoming traceparent header (W3C Trace Context)
2. Creates a child span for its work
3. Adds business-relevant attributes (user.id, tenant.id, request_id, model, tokens)
4. Propagates traceparent on outbound calls
5. Emits structured logs that include trace_id + span_id

Python (FastAPI)¶

from opentelemetry import trace
from opentelemetry.instrumentation.fastapi import FastAPIInstrumentor
from azure.monitor.opentelemetry import configure_azure_monitor

# One-line setup — auto-instruments FastAPI, requests, urllib3, sqlalchemy, etc.
configure_azure_monitor(
    connection_string=os.environ["APPLICATIONINSIGHTS_CONNECTION_STRING"]
)

app = FastAPI()
FastAPIInstrumentor.instrument_app(app)

tracer = trace.get_tracer(__name__)

@app.post("/chat")
async def chat(req: ChatRequest):
    with tracer.start_as_current_span("rag-grounding") as span:
        span.set_attributes({
            "user.id_hash": hash_user(req.user_id),
            "tenant.id": req.tenant_id,
            "rag.corpus": req.corpus,
        })
        # ... do work
        span.set_attribute("rag.docs_retrieved", len(docs))

TypeScript (React)¶

import { WebTracerProvider } from "@opentelemetry/sdk-trace-web";
import { AzureMonitorTraceExporter } from "@azure/monitor-opentelemetry-exporter";
import { registerInstrumentations } from "@opentelemetry/instrumentation";
import { FetchInstrumentation } from "@opentelemetry/instrumentation-fetch";

const provider = new WebTracerProvider();
provider.addSpanProcessor(
    new BatchSpanProcessor(
        new AzureMonitorTraceExporter({
            connectionString: import.meta.env
                .VITE_APPINSIGHTS_CONNECTION_STRING,
        }),
    ),
);
provider.register();

registerInstrumentations({
    instrumentations: [
        new FetchInstrumentation({
            propagateTraceHeaderCorsUrls: [/api\.mycompany\.com/],
        }),
    ],
});

Pattern: structured logging with correlation¶

Every log line includes the trace ID:

import structlog
from opentelemetry import trace

def add_trace_context(logger, method_name, event_dict):
    span = trace.get_current_span()
    if span:
        ctx = span.get_span_context()
        event_dict['trace_id'] = format(ctx.trace_id, '032x')
        event_dict['span_id'] = format(ctx.span_id, '016x')
    return event_dict

structlog.configure(processors=[
    add_trace_context,
    structlog.processors.JSONRenderer(),
])

log = structlog.get_logger()
log.info("rag_retrieved", docs_count=len(docs), user_id_hash=hash_user(uid))

In App Insights you can join logs to traces by trace_id.

Pattern: SLI / SLO / error budget¶

Define what "working" means as numbers:

When you blow your error budget, engineering work shifts from features to reliability until you're back inside budget. This forces honest conversations.

Pattern: dashboards in Azure Workbooks¶

Don't reinvent. Workbooks ship a few good templates and the platform extends them:

• Service Health — uptime, error rate, latency p50/p95/p99 per service
• Trace Explorer — slowest 100 traces, filter by service / operation / error
• AOAI Cost — token usage by deployment / day / feature, $ trend
• RAG Quality — recall, citation precision, refusal rate over time
• Drift — weekly eval scores vs baseline

Workbook JSON lives under deploy/bicep/shared/modules/workbooks/ (planned — see roadmap). Until then, Workbook templates can be exported from the portal and committed.

Pattern: alerts that don't page-fatigue¶

Rules of thumb:

• Sev 1 wakes someone up. Reserve for "service is down."
• Sev 2 ticks during business hours. "Significant degradation."
• Sev 3 is a ticket for next-day investigation. "Something's off."
• More than 1-2 Sev 1 pages / week → recalibrate; alerts are too noisy.

Pattern: correlation across the boundary¶

For a chat request:

trace_id = 4bf92f3577b34da6a3ce929d0e0e4736

[browser]   span: page-load               trace_id=4bf9... duration=200ms
  [browser]   span: HTTP POST /chat       trace_id=4bf9... duration=1240ms
    [BFF]      span: chat handler         trace_id=4bf9... duration=1230ms
      [BFF]      span: rate-limit check   trace_id=4bf9... duration=2ms
      [BFF]      span: rag.grounding      trace_id=4bf9... duration=850ms
        [RAG]      span: retrieve         trace_id=4bf9... duration=120ms
        [RAG]      span: aoai-completion  trace_id=4bf9... duration=720ms
      [BFF]      span: response-build     trace_id=4bf9... duration=10ms

Click any span in App Insights → see the full waterfall + every log line associated with each span.

Anti-patterns¶
